High brightness transparent glass window clear led screen board size 1000*500
♦ Transparent LED Screen Advantages
1. Nice appearance and simple structures.
2. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
3. Humanized operating interface with breakdown indicator lights, easy to maintain.
4. Jointed correctly, being installed & dismounted by one person without tool.
♦ Transpaent LED Screen Applications
--- Outdoor and indoor advertising, digital billboards, advertising companies
--- Airports, bus stations and railway passenger terminals.
--- Architecture and social projects, information systems in cities.
--- Show-business, concerts, festivals, motor shows and other public events.
--- Sports halls, fields, playgrounds,school church
--- Facades of shopping malls, department stores, banks and car dealerships.
♦ Technical specification
| Item | Specifications |
| LED Module | Color configuration | SMD2121/1921 1R1G1B 3 in 1 |
| Pixel Pitch(mm) | 3.91x7.81mm | 7.81*7.81mm |
| Module Size(mm) | 500(W)× 125(H) |
| Module Weight(kg) | 0.35 |
| Module Max Power(W) | 25 |
| Module Quantity(W×H) | 2×4 |
| Cabinet | Cabinet Resolution(W×H) | 256×64 | 128×64 |
| Cabinet Size(mm) | 1000(W)×500(H)×80(D) |
| Cabinet Weight(kg) | ≤6 |
| Pixel Density(Dot/m2) | 16384 |
| Transparency | 55%-72% |
| Cabinet Material | Die Casting Aluminum |
| Optical parameter | Brightness Control Level | 256 degree by software |
| Brightness Control Mode | Automatically/Manul Operation |
| Brightness at White(nits) | ≥800, can be adjusted |
| Viewing Angel(H/V°) | 140/140 |
| Max. Power(W/㎡) | 380 |
| Ave.Power(W/㎡) | 190 |
| AC Input | AC110~220V10%, 50~60Hz, |
| Drive Mode | 1/16Scan | 1/8Scan |
| Grey Scale | 16bits |
| Refresh rate | ≥3840Hz/s,can be adjusted |
| Life Span | >100,000H |
| Working Temperature,Humidity | -20℃~+50℃, |
Screen Show
♦ Packaging and Shipping
1. Wooden case or flight case package
2. Shipping by sea,air or DHL,multiple shipping ways
Production Process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing
Our team will be forever here to offer you full supports !!!
